8R 310Tractor

Engine kW (hp): 228 kW (310 hp)
Fully integrated precision ag technology
Choice of PowerShift, e23 and AutoPower transmissions
Independent Link Suspension (ILS™)
Three cab and visibility packages available to customize your tractor

Locate a Dealer

View Product Brochure

Print

8R 310

Locate a Dealer

Specifications

Specifications

Select Different Model

Specifications

John Deere

8R 310

Tractor

Export to Excel

1 2

Key Specs

Engine description	John Deere PowerTech™ 9.0 L (B20 diesel compatible)
Engine displacement	9.0 L549 cu in.
Rated engine power	ECE-R120: 228 kW310 hp
Maximum engine power	191 kW257 hp
Rated PTO power (hp SAE)	149 kW200 hp
Transmission type	Standard: e23™ PowerShift™ with Efficiency Manager™ 40K, 40 km/h24.9 mphOptional: 16-speed PowerShift 40 km/he23 PowerShift with Efficiency Manager 50K, 50 km/h31 mphJohn Deere AutoPowr™ IVT™ 40K, 0.05-42 km/h0.03-26 mphJohn Deere AutoPowr IVT 50K, 0.05-50 km/h0.03-31 mph
Hydraulic pump rated output	Standard: 85-cc pump: 227.1 L/min60 gpmOptional: 85-cc plus 35-cc dual pump: 318 L/min84 gpm
Rear hitch category (SAE designation)	Standard: Category 4N/3 standard lift at 610 mm (24 in.) behind hitch point: 9072 kg20,000 lbOptional: Category 4N/3 at 610 mm (24 in.) behind hitch point: 6803 kg15,000 lb
Base machine weight	MFWD/PowerShift: 11,700 kg25,800 lbILS™/e23: 12,700 kg28,000 lb

ENGINE SPECIFICATIONS

Description	John Deere PowerTech 9.0 L (B20 diesel compatible)
Engine type	In-line six, four valve
Engine family	MJDXL09.0333
Rated speed	2100 rpm
Aspiration	Single, variable geometry turbo; air-to-air aftercooling and cooled exhaust gas recirculation
Cylinders liners	Wet-sleeve
Emission level	Final Tier 4
After treatment type	Diesel oxidation catalyst (DOC)/diesel particulate filter (DPF)/selective catalytic reduction (SCR)
Displacement	9.0 L549 cu in.

ENGINE PERFORMANCE

Rated power	ECE-R120: 184 kW250 hp
Rated PTO power (hp SAE)	149 kW200 hp
Power boost	10 percent
Maximum engine power	ECE-R120: 251 kW341 hp
Engine peak torque	At 1600 rpm: 1452 Nm1070 lb-ft
PTO torque rise	40 percent

TRANSMISSION

Type	Standard: e23 PowerShift with Efficiency Manager 40K, 40 km/h24.9 mphOptional: 16-speed PowerShift 40 km/he23 PowerShift with Efficiency Manager 50K, 50 km/h31 mphJohn Deere AutoPowr IVT 40K, 0.05-42 km/h0.03-26 mphJohn Deere AutoPowr IVT 50K, 0.05-50 km/h0.03-31 mph

HYDRAULIC SYSTEM

Type	Closed-center, pressure/flow compensated system with load sensing
Pump rated output	Standard: 85-cc pump: 227.1 L/min60 gpmOptional: 85-cc plus 35-cc dual pump: 318 L/min84 gpm
Available flow at a single rear SCV	1.3-cm (1/2-in.) couplers: 132 L/min35 gpm1.9-cm (3/4-in.) coupler: 159 L/min42 gpm
Available flow at front SCVs	96 L/min25 gpm
Number of rear selective control valves (SCVs)	Standard: 1.3-cm (1/2-in.) ISO couplers: 4Optional: 1.3-cm (1/2-in.) ISO couplers: 5 and 6 available1.9-cm (3/4-in.) ISO coupler: 1
SCV control	Electronic

REAR HITCH

Hitch category (SAE designation)	Standard: Category 4N/3 standard lift at 610 mm (24 in.) behind hitch point: 9072 kg20,000 lbOptional: Category 4N/3 at 610 mm (24 in.) behind hitch point: 6803 kg15,000 lb
Maximum lift capacity behind lift points	Standard (at 610-mm [24-in.] behind hitch point): 12,124 kg26,729 lb
Sensing type	Electrohydraulic
Rear axle differential lock	Electrohydraulic

DRAWBAR

Drawbar category	Standard: Category 4Optional: Category 4 with heavy-duty support
Maximum vertical load	Dependent on drawbar position: 1837 to 2700 kg4050 to 6000 lbOptional: 2,245 kg4,950 lb4,990 kg11,000 lb

REAR POWER TAKE-OFF (PTO)

Type	IndependentStandard: 44 mm (1.75 in.) 20-spline, 1,000 rpmOptional: 44 mm (1.75 in.), 20-spline, 1,000 rpm capable of 35 mm (1.375 in.) 540/1000 rpm44 mm (1.75 in.) 20-spline, 1,000 rpm/1,000E rpm
Engine rpm (at rated PTO speeds)	16-speed PowerShift: 1,000 PTO rpm at 2,003 engine rpm, 1,000 ECO PTO rpm at 1,596 engine rpm, 540 PTO rpm at 1,817 engine rpmIVT: 1,000 PTO rpm at 2,000 engine rpm, 1,000 ECO PTO at 1594 engine rpm, 540 PTO rpm at 1,814 engine rpme23 PowerShift: 1,000 PTO rpm at 1,995 engine rpm, 1,000 ECO PTO at 1,590 engine rpm, 540 PTO rpm at 1,810 engine rpm
Multispeed PTO option availability	Available: 45-mm (1.75-in.), 1000-rpm and 1000E economy rpm PTO, in-cab shiftable
PTO actuation	Electrohydraulic with adjustable modulation

FRONT HITCH

Category	Category 3N
Standard lift capacity	Category 3N ground-engaging front hitch: 5200 kg11,464 lb
Front power take-off (PTO)	44 mm (1.75 in.) 20 spline, 1000 rpm35 mm (1.375 in.) 21 spline, 1000 rpm35 mm (1.375 in.) 6 spline, 1000 rpm (available dependent on location)
PTO speed	1,000 PTO rpm at 2000 engine rpm

REAR AXLE

Type	Standard: Rack-and-pinion, double flat, or flange axlesOptional: Long, dual taper hub: Diameter: 110 x 3010 mm4.33 x 118.5 in.Short, double flat axle with single taper hub: Diameter: 120 x 2550 mm4.72 x 100.4 in.
Final drive type	Inboard planetary three pinion
Rear differential lock	Full-locking electrohydraulic

FRONT AXLE

Type	Standard: ILSOptional: 1500 Series MFWD
Front axle differential lock	1500 Series MFWD: Full-locking electrohydraulicILS: Full-locking electrohydraulic

TIRES

Wheel tread range	1500 Series MFWD: 1524-3657 mm60-144 in.ILS: 1524-3657 mm
Turning radius without brakes	1500 with 420/850R34 Group 43 tires at 182.9-cm (72-in.) spacing: 5.71 m18.7 ftILS with 480/70R34 Group 43 tires at 184.2-cm (72.5-in.) spacing: 6.45 m21.2 ft
Central Tire Inflation System (CTIS)	Optional

STEERING

Type	Standard: Hydraulic power-steering with electric pump back-upOptional: ActiveCommand Steering 2 (ACS™ 2) with electronic backup pump

ELECTRICAL SYSTEM

Alternator size	Standard: 200 ampOptional: 330 amp
Battery options	12 V
Working lights	Standard: 18 halogenAvailable: 18 LED22 LED
Type of bulb in headlight (Halogen, Zenon, LED)	Standard: halogen, 65 WAvailable: LED
Total cold cranking amps	1,850 CCA

OPERATOR STATION

Seat	Degree of seat swivel, left hand25 degree (angle)Degree of seat swivel, right hand40 degree (angle)Standard: air suspensionOptional: ActiveSeat™ II
Cab suspension	Optional
Instructional seat	Standard
Display	Standard: 4600 Generation 4 CommandCenter™: 25.4 cm10 in.
Radio	Standard: AM/FM stereo with weatherband, remote controls, auxiliary input jack, four speakers and external antenna
Inner cab volume	3.24 m3114 cu ft
Cab glass area	6.52 m270.18 sq ft

DIMENSIONS

Wheelbase	MFWD: 3,080 mm121.3 in.ILS: 3,050 mm120.1 in.
Overall length	6,636 mm261.3 in.
Drawbar clearance	376 mm14.8 in.
Front axle center	MFWD: 686 mm27 in.ILS: 590 mm23.2 in.

WEIGHT

Base machine weight	MFWD/PowerShift: 11,700 kg25,800 lbILS™/e23: 12,700 kg28,000 lb
Maximum ballast level	20,000 kg44,100 lb
Maximum permissible weight	20,000 kg44,100 lb

CAPACITIES

Crankcase oil volume	1500 MFWD: 27.6 L7.3 U.S. gal.ILS: 25.8 L6.8 U.S. gal.
Fuel tank	727 L192 U.S. gal.CTIS: 651 L172 U.S. gal.
Diesel exhaust fluid (DEF) tank	37.2 L9.8 U.S. gal.
Cooling system	42.3 L11.2 U.S. gal.
Transmission-hydraulic system	1500 MFWD: 184.6 L48.8 U.S. gal.ILS: 207.2 L54.7 U.S. gal.

SERVICEABILITY

Interval for engine oil change	500 hours
Interval for hydraulic/transmission oil change	1,500 hours
Interval for engine coolant change	6,000 hours

LOADERS

Loader	700M

PRECISION AG

Guidance	Integrated AutoTrac™
Telematic	JDLink™ hardware standard, activations, and Ethernet harnesses (availability dependent upon destination)
Remote diagnostics	JDLink hardware standard

MISCELLANEOUS

Country of manufacture	USA

ADDITIONAL INFORMATION

Date collected	12 January 2022
