615PBelt Pickup Platform
• Hydraulic adjustable windscreen maximizes control
• Dual-belt draper pickup
• Steel auger fingers
• Fixed gauge wheels reduce width of platform
Features
Expand All
Collapse All
615P hydraulic windscreen
Manual tilt adjustment for windscreen
Crop transition on 615P
The 615P features 4.5-m (178-in.) wide belts for enhance belt tracking with reduced seed loss.
615P belt tensioning
615P suspension system
Windscreen on 615P
615P hydraulic windscreen
The hydraulic windscreen on the 615P allows the operator to maximize productivity by controlling the crop flow in changing windrow conditions.
Feature benefit:
- Adjustments made from the cab
- Control crop flow in changing windrow conditions
FUNCTIONALITY:
Manual tilt adjustment for windscreen
The hydraulic windscreen utilizes double-acting cylinders which react quicker in maximizing the control of the crop. The windscreen is controlled by the fore-and-aft control on the combine hydro handle. A benefit is the header backshaft speed can be controlled independently of the windscreen allowing for increased belt pickup, auger/feederhouse chain speed for tough windrow conditions.
Dual draper belts on 615P
Crop transition on 615P
The 615P features a dual-belt draper to enhance material flow into the combine when harvesting windrows.
Feature benefit:
- Smooth material flow into the auger
- Increased material handling capacity
- Allows crop to fall from the pickup belts
FUNCTIONALITY:
The transfer belts move crop under the 66-cm (26-in.) diameter auger. This provides significant material handling advantages in large/dense windrows.
615P wide belts improve feeding
615P
The 615P features 4.5-m (178-in.) wide belts for enhance belt tracking with reduced seed loss.
Feature benefit:
- Eliminates the need for a complicated center-support roller
- Reduces seed loss
- Improved belt tracking
FUNCTIONALITY:
Connectors between belts improve belt-drive capacity in tough windrow conditions without the need for a center support on the drive rollers. This design eliminates roller flanges which would create a gap between belts and could result in crop losses. The heavy-duty 615P belts are designed for maximum wear life.
615P belt tensioning system
615P belt tensioning
The 615P features a belt tensioning system for extended belt and roller life.
Feature benefit:
- Belts are evenly tensioned for uniformed loading
- Easy adjustment that requires minimal tools
- Minimizes seed loss
FieldGlide™ suspension system on 615P
615P suspension system
The exclusive FieldGlide suspension system features an adjustable air spring and heavy-duty hydraulic shock design to dampen movement during field operation, allowing the operator to increase harvesting speed. Once set, the air springs do not need adjustment during the season.
Feature benefit:
- Improves windrow harvesting performance
- Harvest at faster speeds
- No tools needed
FUNCTIONALITY:
Adjustment of the air springs requires no tools and is simple compared to other belt pickup suspensions. Adjust the air springs according to instructions located on the belt pickup side sheets. No tools needed or springs to adjust.
Specifications
| Specifications | ||||
|---|---|---|---|---|
| John Deere 615P Belt Pickup Platform |
Header
| Transport widths | 5,438 mm 210.5 in. |
|||
|---|---|---|---|---|
| Header height control | Hydraulic |
Pickup Belts
| Width of belts | 1,130 mm 44.5 in. |
|||
|---|---|---|---|---|
| Number of belts per pickup | 4 picking, 4 transfer | |||
| Total picking width | 4,546 mm 179 in. |
|||
| Operating speed of belts | 3-150 m/min 10-475 fpm |
|||
| Number of rollers | 2 picking, 2 transfer |
Pickup Fingers
| Type | Plastic | |||
|---|---|---|---|---|
| Number of fingers per belt | 84 |
Auger
| Float range | 57 mm 2.25 in. |
|||
|---|---|---|---|---|
| Diameter | 662 mm 26 in. |
|||
| Auger fingers | Heavy-duty, round, diameter with breakaway notch 15.9 mm 0.625 in. |
|||
| Number of auger fingers | 19 STS, maximum 22 | |||
| Auger finger pattern | In-line, retracting | |||
| Finger reach | 152 mm 6 in. |
|||
| Operating speed | At 520 feederhouse speed 180 rpm\ |
Tires
| Pressure | 1 bar 103.4 kPa 15 psi |
|---|
Weight
| Approximate shipping weight (includes shipping skids) | 1,520 kg 3,350 lb |
|---|
